Qu’est-ce que le Liquefied Natural Gas (LNG)? et comment faire le plein?
En refroidissant le gaz naturel à-162°c, il se transorme en liquide et diminue à 1/600ième de son volume original. Ce process permet de le transporter plus facilement vers les clients. Jetez un coup d'oeil à la video afin de connaître le processus.
Vous souhaitez plus d’information?
Si vous avez des questions ou si vous souhaitez avoir plus d’information sur les avantages que peut apporter Shell LNG à votre entreprise, merci de nous contacter en cliquant ici.
LNG-Vehicles with separate vapour return, as present in Iveco and Scania LNG vehicles
Title: Shell LNG Refuel (Iveco/Scania trucks)
Duration: 5:34
Description:
This video provides the basic HSSE information around LNG, followed by a step-by-step instructions on how to correctly perform the refueling process with a Iveco/Scania LNG Truck (with separate vapor return).
LNG refuelling instructions at a Shell station
For vehicles with separate vapour return (for example Scania and Iveco)
CAUTION:
Exposure to LNG can cause severe cold burns or frostbite.
You must wear personal protective equipment (PPE)
STOP
Warning
In case of emergency
- press shutdown button
- evacuate the area
- notify staff via intercom
STEP 1
Park vehicle, engage parking brake, turn off engine
STEP 2
Check dispenser availability
STEP 3
Put on Personal Protective Equipment (PPE)
STEP 4
Connect earthing cable
STEP 5
Check tank pressure
STEP 6
Vapour return procedure (if necessary)
STEP 7
Remove tank cap, clean LNG receptacle
STEP 8
Clean and connect LNG nozzle
CAUTION:
DO NOT use excessive force
This can cause damage to receptacle or nozzle and may lead to LNG spillage
STEP 9
Start transaction at payment terminal
STEP 10
Press and hold START button
STEP 11
Pump stops when tank is full
STEP 12
Disconnect LNG nozzle
STEP 13
Clean LNG nozzle and connections
STEP 14
Replace tank cap
STEP 15
Disconnect earthing cable
STEP 16
Remove Personal Protective Equipment (PPE)
STEP 17
Finish transaction at payment terminal
CAUTION:
Before starting your vehicle please ensure
- nozzles and earthing disconnected and stowed
- tank cap properly attached
- vehicle and dispenser free of leaks
LNG-Vehicles with vapour return via the LNG-nozzle, as present in Volvo LNG vehicles
Title: Shell LNG Refuel (Volvo trucks)
Duration:5:37
Description:
This video provides the basic HSSE information around LNG, followed by a step-by-step instructions on how to correctly perform the refueling process with a Volvo LNG Truck (vapor return via the LNG-nozzle).
LNG refuelling instructions at a Shell station
For vehicles with vapour return via the LNG nozzle (for example Volvo)
CAUTION:
Exposure to LNG can cause severe cold burns or frostbite symptoms.
You must wear personal protective equipment (PPE)
STOP
Warning
In case of emergency
- press shutdown button
- evacuate the area
- notify staff via intercom
STEP 1
Park vehicle, engage parking brake, turn off engine
STEP 2
Check dispenser availability
STEP 3
Put on Personal Protective Equipment (PPE)
STEP 4
Connect earthing cable
STEP 5
Remove tank cap, clean LNG receptacle
STEP 6
Clean and connect LNG nozzle
CAUTION:
DO NOT use excessive force
This can cause damage to receptacle or nozzle and may lead to LNG spillage
STEP 7
Check tank pressure
STEP 7a
vapour return procedure (if necessary)
STEP NEW
for Volvo-only: Select “Extra cold LNG” (if available at station)
STEP 8
Start transaction at payment terminal
STEP 9
Press and hold START button
STEP 10
Pump stops when tank is full
STEP 11
Disconnect LNG nozzle
STEP 12
Clean LNG nozzle and connections
STEP 13
Replace tank cap
STEP 14
Disconnect earthing cable
STEP 15
Remove Personal Protective Equipment (PPE)
STEP 16
Finish transaction at payment terminal
CAUTION:
Before restarting your vehicle please ensure
- nozzles, hoses and earthing disconnected and stowed
- tank cap properly attached
- vehicle and dispenser free of leaks
